XK6140 CNC Milling Machine

Optional configuration:

• System:GSK,KND

• CNC dividing head

• Top Tailstock

• Pneumatic broach

• Fully protected sheet metal

• The table rotate

• PARAMETER ITEM	UNIT	XK6140
  Size of worktable	mm	1700*400
  Table travel	mm	1000*330*400
  T-groove	mm	3-18-90
  SpindleTaper	-	ISO:50/7:24
  Table rotation angle(optional)	。	±45。
  Distance between spindle end face and table top	mm	30-410
  Bed Vertical Guide to the spindle center line distance	mm	275-625
  Spindle speed range (series)	rpm	30-1500/18
  Fast moving speed (x/y/z)	mm/min	6000/3000/6000
  Positioning accuracy	mm	0.05/300
  Repeat positioning accuracy	mm	0.025/300
  Main Drive motor power	kw	11
  Cooling pump motor power	kw	0.125
  External dimensions	mm	3310*2200*2394
  Weight of machine tool	kg	4250
