Universal Lift Table Milling Machine X6032
NO.1 MACHINERY
8459619000
Optional configuration:
Vertical milling head
Three-axis digital display
Electronic oil pump
Universal dividing head
Custom tool holder
PARAMETER ITEM | UNIT | X6032 |
Working desk size | mm | 1500*320 |
Number of T-slots | 3 | |
Workbench trip | mm | 1000*320*400 |
Spindle hole taper | 7:24/ISO40 | |
Spindle speed range | rpm | 40-1300(12 steps) |
Worktable feed speed | mm/min | 15-370(8 steps) |
Workbench,downstroke | mm | 500 |
Worktable vertical lifting speed | mm/min | 560 |
Spindle center to vertical rail surface distance | mm | 320 |
Vertical shaft end to table distance | mm | 50-550 |
Motor Power | kw | 3 |
Dimensions | mm | 1760*1500*1900 |
Machine weight | kg | 2100 |
